Outer Casing: Die cast aluminium
Fins: Die cast aluminium
Controls: Digital LCD display, controls and screen
Safety: Overheat temperature protection.
IP Rating: IP20
Installation: Wall mounting kit included and must be used.
Electrical Connection:
Installation must comply with current IEE regulations.
The product should be connected to the fixed wiring of the property via a double pole fused spur with a minimum break capacity of 13 amps
Cable pre-wired (1.4m),
White cable,
Cable entry to the bottom right of the unit.
Electrical Isolation: Class I
Approvals: CE
Standard Warranty: 1 year parts or replacement warranty.
Order Code | Height (mm) | Width (mm) | Depth (mm) | Weight (kg) |
AVG600T | 575 | 480 | 80 | 8.5 |
AVG900T | 575 | 560 | 80 | 10.0 |
AVG1500T | 575 | 800 | 80 | 15.5 |
AVG1800T | 575 | 960 | 80 | 19.0 |
